Computer data lines circuit, w/o propilot assist for Infiniti QX55 I (2020-2024)

ADAS CAN COMM 1-H ADAS CAN COMM 1-L ADAS CAN COMM 2-H ADAS CAN COMM 2-L BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CHASSIS CAN COMM 1 H CHASSIS CAN COMM 1 L DATA LINK CONNECTOR DIAGNOSTIC CAN COMM H DIAGNOSTIC CAN COMM L FUSE 20 FUSE 53 FUSE 55 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED IGN K LINE LT GRN WIRE OCCUPANT CLASSIFICATION SYSTEM CONTROL UNIT PNK WIRE RED WIRE STEERING ANGLE SENSOR STEERING COLUMN ASSEMBLY VEHICLE CAN COMM 1 H VEHICLE CAN COMM 1 L VEHICLE CAN COMM 2 H VEHICLE CAN COMM 2 L WHT WIRE YEL WIRE

A/C AUTO AMP ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) AFS CONTROL UNIT AIR BAG DIAGNOSIS SENSOR UNIT BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER ELECTRIC PARKING BRAKE CONTROL MODULE ELECTRIC SHIFT CONTROL MODULE GRN WIRE GRY WIRE HEAD UP DISPLAY UNIT LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L PNK WIRE RED WIRE UNIFIED METER CONTROL UNIT) WHT WIRE YEL WIRE

AUTOMATIC BACK DOOR CONTROL MODULE AWD CONTROL UNIT BCM (BODY CONTROL MODULE) BLU WIRE BRN WIRE CAN L CAN-H GRN WIRE GRY WIRE INTEGRAL SWITCH ITS CAN-H ITS CAN-L LEFT SIDE RADAR LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L PNK WIRE PPL RED WIRE TOTAL ILLUMINATION CONTROL UNIT V CAN-H V CAN-L WHT WIRE YEL WIRE

ACTIVE NOISE CONTROL UNIT ATR CONTROL MODULE BLU WIRE BOSE SPEAKER AMP BRN WIRE CAN L CAN-H DRIVER SEAT CONTROL UNIT ELECTRIC INTAKE VALVE TIMING CONTROL MODULE EPS CONTROL UNIT GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L PNK WIRE PPL RED WIRE TOP OF TRANSMISSION) W/ MEMORY W/O BOSE AUDIO SYSTEM WHT WIRE YEL WIRE

ADAS CONTROL UNIT (BASE OF LEFT "D" PILLAR) BLU WIRE BRN WIRE CAN L CAN-H CHASSIS CONTROL MODULE DRIVETRAIN GRN WIRE GRY WIRE IC CAN H IC CAN L ITS CAN-H ITS CAN-L LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE TCM (TRANSMISSION CONTROL MODULE) V CAN-H V CAN-L VCR CONTROL MODULE WHT WIRE YEL WIRE

ACCELERATOR PEDAL ACTUATOR/ ACCELERATOR PEDAL POSITION SENSOR AROUND VIEW MONITOR CONTROL UNIT BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CENTER CONSOLE DISTANCE SENSOR FRONT CAMERA UNIT IGN IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) IT CAN COMM H IT CAN COMM L LT BLU WIRE LT GRN WIRE M CAN-H M CAN-L PNK WIRE PPL RED WIRE RIGHT SIDE RADAR SONAR CONTROL UNIT VEHICLE CAN COMM 2 H VEHICLE CAN COMM 2 L W/ INTELLIGENT CRUISE CONTROL YEL WIRE
