Infiniti QX55 I (2020-2024) right outer front sonar sensor Wiring diagram
This page shows the only wiring diagram for the component.right outer front sonar sensor, which is found in the car Infiniti QX55 I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right outer front sonar sensor (1 of 1)
AV CONTROL UNIT (CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CAN-H PPL CAN-L
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FR SENSOR GND
FR SENSOR POWER
FUSE 55
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
ITS SWITCH ASSEMBLY (SONAR CONTROL SWITCH)
LEFT INNER FRONT SONAR SENSOR
LEFT INNER REAR SONAR SENSOR
LEFT OUTER FRONT SONAR SENSOR
LEFT OUTER REAR SONAR SENSOR
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RIGHT INNER FRONT SONAR SENSOR
RIGHT INNER REAR SONAR SENSOR
RIGHT OUTER FRONT SONAR SENSOR
RIGHT OUTER REAR SONAR SENSOR
RIL SENSOR SIGNAL
RIR SENSOR SIGNAL
ROL SENSOR SIGNAL
ROR SENSOR SIGNAL
RR SENSOR GND
RR SENSOR PWR
SIGNAL FIL
SIGNAL FIR
SIGNAL FOL
SIGNAL FOR
SONAR BUZZER (LEFT SIDE OF DASH)
SONAR CONTROL UNIT (RIGHT SIDE OF DASH)
SPEAKER FR SIGNAL
SPEAKER PWR
STATUS LED
SWITCH INPUT
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
YEL WIRE
Go to component: -> Sonar circuit -> RIGHT OUTER FRONT SONAR SENSOR
