Car Wiring Diagrams for Climate control seats circuit for Infiniti QX50 II (2017-2024)

A/C AUTO AMPLIFIER (RIGHT SIDE OF DASH) AUTO ACC BLK WIRE BLU WIRE CAN L CAN-H CCS (GND) CCS (IGN) CCS (LIN) CLIMATE CONTROLLED SEAT RELAY COMPUTER DATA LINES SYSTEM FUSE 22 FUSE 32 FUSE 37 FUSE 55 FUSE BLOCK (J/B) GRN WIRE HEAT SENSOR HEATER HEATER (IGN) HEATER (NTC-IN) HEATER (NTC-OUT) HEATER/CCS (GND) HOT W/ ACCESSORY RELAY-1 ENERGIZED HOT W/ IGNITION RELAY-2 ENERGIZED HTR SEAT DR GND LEFT CLIMATE CONTROLLED SEAT BLOWER UNIT LEFT FRONT SEAT HEATER (LEFT FRONT SEAT CUSHION) LEFT SEAT BACK HEATER LEFT SEAT CUSHION HEATER MAIN PNK WIRE POWER DISTRIBUTION SYSTEM PPL RED WIRE RIGHT CLIMATE CONTROLLED SEAT BLOWER UNIT RIGHT FRONT SEAT HEATER (RIGHT FRONT SEAT CUSHION) RIGHT SEAT BACK HEATER RIGHT SEAT CUSHION HEATER SUB HEATER WHT WIRE YEL WIRE
