Infiniti QX50 II (2017-2024) Memory systems circuit

ADP STEERING SWITCH AUTOMATIC DRIVE POSITIONER CONTROL UNIT BACKWARD BAT (PTC) BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE BWD CAN L CAN-H CIRCUIT BREAKER 2 COMPUTER DATA LINES SYSTEM DOWNWARD FORWARD/ FUSE 2 FUSE 20 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK I GND PWR GND SENS GND GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT DOOR SWITCH LT BLU WIRE LT GRN WIRE MIR MTR LH (HORIZ LEFT) MIR MTR LH COM (DOWN RH) MIR MTR LH VERT (UP) MIR MTR RH COM (DOWN RH) MIR MTR RH HORIZ (LEFT) MIR MTR RH VERT (UP) MIR SELECT SW (LH) MIR SELECT SW (RH) MIR SENS (LH HORIZ) MIR SENS (LH VERT) MIR SENS (RH HORIZ) MIR SENS (RH VERT) MIR SW (DOWNWARD) MIR SW (LEFTWARD) MIR SW (RIGHTWARD) MIR SW (UPWARD) PNK WIRE PPL PPL PNK WIRE PWR ECU RED WIRE STRG MTR COM (UP/FWD) TELESCOPIC MTR (BACKWARD) TELESCOPIC SW (BACKWARD) TELESCOPIC SW (FRONTWARD) TELESCOPIC SWITCH TILT MTR (DOWNWARD) TILT SW (DOWNWARD) TILT SW (UPWARD) TILT SWITCH TILT, TELESCOPIC MOTOR (STEERING COLUMN ASSEMBLY) UART (TX/RX) UPWARD WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE DEFOGGER SYSTEM GRN WIRE GRY WIRE LEFT DOOR MIRROR LT BLU WIRE LT GRN WIRE MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH (DOOR MIRROR REMOTE CONTROL SWITCH) MEM IND 1 MEM IND 2 MEM SW 1 MEM SW 2 MIRROR HEATER MIRROR SWITCH NAVIGATION SYSTEM PNK WIRE PPL PPL PNK WIRE RED WIRE RIGHT DOOR MIRROR SEAT MEMORY SWITCH SELECT SWITCH SET SW SHIELD SIDE CAMERA TAN WIRE TURN WHT WIRE YEL WIRE

ADDRESS 2 ADDRESS-1 BAT (PTC) BLK WIRE BLU WIRE BRN WIRE BWD CAN L CAN-H COMPUTER DATA LINES SYSTEM DOWNWARD DRIVER SEAT CONTROL UNIT DWN FRONT LIFTER MTR (UPWARD) FRONT LIFTER SW (DOWNWARD) FRONT LIFTING SWITCH FRT LIFTER MTR (DOWNWARD) FRT LIFTER SW (UPWARD) GRN WIRE GRY WIRE IND 1 IND 2 LEFT FRONT LIFTING MOTOR LEFT POWER SEAT SWITCH LEFT REAR LIFTING MOTOR LEFT RECLINING MOTOR LEFT SLIDING MOTOR LT BLU WIRE LT GRN WIRE PNK WIRE PPL PULSE (FRONT LIFTER) PULSE (REAR LIFTER) PULSE (RECLINER) PULSE (SLIDE) PULSE (TELESCOPIC) PULSE (TILT) PWR SPLY (ENCODER) REAR LIFTER MTR (DOWNWARD) REAR LIFTER MTR (UPWARD) REAR LIFTER SW (DOWNWARD) REAR LIFTER SW (UPWARD) REAR LIFTING SWITCH RECLINER MTR (BACKWARD) RECLINER MTR (FORWARD) RECLINER SW (BACKWARD) RECLINER SW (FORWARD) RECLINING SWITCH RED WIRE SET SW SLIDE MTR (BACKWARD) SLIDE MTR (FORWARD) SLIDE SW (BACKWARD) SLIDE SW (FORWARD) SLIDING SWITCH TAN WIRE UART (TX/RX) UPWARD WHT WIRE YEL WIRE
