Infiniti QX50 II (2017-2024) Ground distribution circuit

ADAS CONTROL UNIT 2 ADAS CONTROL UNIT 2 SHIELD AUTO ANTI-DAZZLING INSIDE MIRROR AUTOMATIC BACK DOOR CLOSE SWITCH BACK DOOR LOCK ASSEMBLY (DOOR AJAR SWITCH) BCM (BODY CONTROL MODULE) BLK WIRE DATA LINK CONNECTOR DRIVE MODE SWITCH ELECTRIC PARKING BRAKE SWITCH ELECTRIC SHIFT SELECTOR FRONT AUXILIARY INPUT JACKS CONTROL UNIT HIGH MOUNTED STOP LAMP ITS SWITCH ASSEMBLY LEFT BLIND SPOT WARNING/ BLIND SPOT INTERVENTION INDICATOR LEFT DOOR MIRROR LEFT FRONT OUTSIDE HANDLE ASSEMBLY LEFT LUGGAGE ROOM LAMP LEFT REAR COMBINATION LAMP (BACK DOOR SIDE) LEFT REAR COMBINATION LAMP (BODY SIDE) LEFT SIDE RADAR MOONROOF MOTOR ASSEMBLY REAR WIPER MOTOR SEAT MEMORY SWITCH STEERING ANGLE SENSOR SUNSHADE MOTOR ASSEMBLY TRAILER CONNECTOR TRAILER LAMP CONVERTER MODULE W/ MOONROOF WHT WIRE

ADP STEERING SWITCH AFS CONTROL UNIT AIR BAG DIAGNOSIS SENSOR UNIT ASCD STEERING SWITCH AV CONTROL UNIT BLK WIRE CANADA CHASSIS CONTROL MODULE COMBINATION SWITCH (SPIRAL CABLE) COMBINATION SWITCH (WIPER, WASHER SWITCH) DONGLE UNIT ELECTRIC SHIFT CONTROL MODULE SHIELDS FORCE MOTOR ANGLE SENSOR SHIELD FROM DATA LINK CONNECTOR (DIAGRAM 1 OF 6) FRONT CAMERA UNIT FRONT POWER SOCKET RELAY FRONT ROOM/ MAP LAMP ASSEMBLY FRONT USB CHARGE PORT FUSE BLOCK (J/B) POWER SOCKET RELAY HEAD UP DISPLAY UNIT ICC STEERING SWITCH INTEGRAL SWITCH ITS SWITCH ASSEMBLY LEFT PERSONAL LAMP LEFT VANITY LAMP LIFT ACCESSORY PRE-WIRE MASTER LIGHT SWITCH MOONROOF SWITCH NCA WIRE PADDLE SHIFTER PUSH BUTTON IGNITION SWITCH RAIN SENSOR REAR AIR CONTROL RIGHT PERSONAL LAMP RIGHT VANITY LAMP SHEILD SONAR CONTROL UNIT STEERING COLUMN ASSEMBLY TCU TELEMATICS SWITCH TOTAL ILLUMINATION CONTROL UNIT TRIP RESET SWITCH USB INTERFACE W/ AROUND VIEW MONITOR SYSTEM W/ INTELLIGENT CRUISE CONTROL SYSTEM W/O INTELLIGENT CRUISE CONTROL SYSTEM

A/C AUTO AMP ADAS CONTROL UNIT AUTOMATIC BACK DOOR MAIN SWITCH AUTOMATIC DRIVE POSITIONER CONTROL UNIT BLK WIRE CLIMATE CONTROLLED SEAT RELAY COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) CONSOLE POWER SOCKET DRIVER SEAT CONTROL UNIT ELECTRIC SHIFT CONTROL MODULE FRONT POWER SOCKET GLOVE BOX LAMP) HEATED STEERING WHEEL IONIZER LEFT CLIMATE CONTROLLED SEAT BLOWER UNIT LEFT FRONT DOOR LOCK ASSEMBLY LEFT FRONT LIFTING MOTOR LEFT FRONT SEAT HEATER LEFT LUMBAR SUPPORT SWITCH LEFT POWER SEAT SWITCH LEFT REAR LIFTING MOTOR LEFT REAR POWER WINDOW SWITCH LEFT REAR SEAT BELT BUCKLE SWITCH LEFT RECLINING MOTOR LEFT SEAT BELT BUCKLE SWITCH LEFT SLIDING MOTOR MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH (DOOR MIRROR REMOTE CONTROL SWITCH) REAR SEAT BELT BUCKLE SWITCH (CENTER) REAR USB CHARGE PORT RIGHT ACCESSORY PRE-WIRE RIGHT DOOR MIRROR RIGHT FRONT OUTSIDE HANDLE ASSEMBLY STEERING COLUMN ASSEMBLY TAN WIRE VARIABLE BLOWER CONTROL W/ MEMORY W/O MEMORY

ACCELERATOR PEDAL ACTUATOR / ACCELERATOR PEDAL POSITION SENSOR SHIELD ACCELERATOR PEDAL ACTUATOR/ ACCELERATOR PEDAL POSITION SENSOR ACTIVE TORQUE ROD SHIELD ATR CONTROL MODULE AUTOMATIC BACK DOOR CONTROL MODULE AWD CONTROL UNIT BLK WIRE BRAKE FLUID LEVEL SWITCH DAYTIME RUNNING LIGHT RELAY DIRECT FUEL INJECTOR RELAY 1, 2 DISTANCE SENSOR ELECTRIC PARKING BRAKE CONTROL MODULE ELECTRIC THROTTLE CONTROL ACTUATOR SHIELD ELECTRIC WASTEGATE CONTROL ACTUATOR SHIELD EPS CONTROL UNIT FUEL INJECTOR RELAY 1 FUEL INJECTOR RELAY 2 FUEL LEVEL SENSOR UNIT, FUEL PUMP SHIELD FUEL PUMP CONTROL MODULE (FPCM) GRY WIRE HIGH PRESSURE FUEL PUMP RELAY HIGH PRESSURE FUEL PUMP RELAY, STARTER CUT RELAY HOOD SWITCH INTAKE MANIFOLD RUNNER CONTROL VALVE MOTOR SHIELD INTELLIGENT KEY WARNING BUZZER IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) MAIN MOTOR ANGLE SENSOR SHIELD MULTI-WAY CONTROL VALVE SHIELD REAR CARGO POWER SOCKET RIGHT FRONT COMBINATION LAMP SHIELD STEERING ANGLE MAIN CONTROL MODULE STEERING ANGLE SUB CONTROL MODULE STEERING TORQUE SENSOR SHIELD SUB MOTOR ANGLE SENSOR SHIELD TOP OF TRANSMISSION) TURBOCHARGER SPEED SENSOR SHIELD W/ INTELLIGENT CRUISE CONTROL W/ PROPILOT ASSIST WASHER FLUID LEVEL SWITCH WIPER DEICER WIPER DEICER RELAY

ACTIVE NOISE CONTROL UNIT AUTOMATIC BACK DOOR WARNING BUZZER BACK DOOR OPENER SWITCH BLK WIRE BOSE SPEAKER AMP BOSE SUBWOOFER AMP ELECTRIC INTAKE VALVE TIMING CONTROL MODULE FRONT WIPER HIGH RELAY FRONT WIPER MOTOR FRONT WIPER RELAY GRN WIRE GRY WIRE HORN (HIGH) HORN (LOW) IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LEFT FRONT COMBINATION LAMP LEFT FRONT FOG LAMP LEFT LICENSE PLATE LAMP MOTION ACTIVATED BACK DOOR CONTROL UNIT OCCUPANT CLASSIFICATION SYSTEM CONTROL UNIT REAR CARGO POWER SOCKET RIGHT BLIND SPOT WARNING/ BLIND SPOT INTERVENTION INDICATOR RIGHT FRONT FOG LAMP RIGHT LICENSE PLATE LAMP RIGHT LUGGAGE ROOM LAMP RIGHT REAR COMBINATION LAMP (BACK DOOR SIDE) RIGHT REAR COMBINATION LAMP (BODY SIDE) RIGHT SIDE RADAR VCR CONTROL MODULE WIPER RELAY

A/C COMPRESSOR (MAGNETIC CLUTCH) ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) AROUND VIEW MONITOR CONTROL UNIT BLK WIRE CONDENSER 1 COOLING FAN CONTROL MODULE GRY WIRE IGNITION COIL 1 (W/ POWER TRANSISTOR) IGNITION COIL 2 (W/ POWER TRANSISTOR) IGNITION COIL 3 (W/ POWER TRANSISTOR) IGNITION COIL 4 (W/ POWER TRANSISTOR) INPUT SPEED SENSOR LEFT REAR SIDE AIR BAG SATELLITE SENSOR SHIELD LEFT SIDE CURTAIN AIR BAG MODULE SHIELD NCA WIRE OUTPUT SPEED SENSOR PRIMARY SPEED SENSOR REAR WINDOW DEFOGGER RIGHT CLIMATE CONTROLLED SEAT BLOWER UNIT RIGHT FRONT SEAT HEATER RIGHT LUMBAR SUPPORT SWITCH RIGHT POWER SEAT SWITCH RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH RIGHT REAR POWER WINDOW SWITCH RIGHT REAR SEAT BELT BUCKLE SWITCH RIGHT REAR SIDE AIR BAG SATELLITE SENSOR SHIELD RIGHT SIDE CURTAIN AIR BAG MODULE SHIELD SHIELD STEERING ANGLE MAIN CONTROL MODULE STEERING FORCE CONTROL MODULE TCM (TRANSMISSION CONTROL MODULE) W/ PROPILOT ASSIST WHT WIRE
