Car Wiring Diagrams for Immobilizer circuit for Infiniti QX50 II (2017-2024)

BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM DONGLE UART DONGLE UNIT (CANADA) (CENTER OF DASH) FUSE 2 FUSE 39 FUSE 50 FUSE BLOCK (J/B) GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED IMMOBILIZER KAZASHI A IMMOBILIZER KAZASHI B NATS ANTENNA PNK WIRE PUSH BUTTON IGNITION SWITCH PWR ECU RED WIRE SECURITY IND SECURITY LED UNIFIED METER CONTROL UNIT WHT WIRE YEL WIRE
