Infiniti QX50 II (2017-2024) vcr motor rotation angle sensor, vcr control shaft 2 rotation angle sensor Wiring diagram
This page shows the only wiring diagram for the component.vcr motor rotation angle sensor, vcr control shaft 2 rotation angle sensor, which is found in the car Infiniti QX50 II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vcr motor rotation angle sensor, vcr control shaft 2 rotation angle sensor (1 of 1)
ACCELERATOR PEDAL ACTUATOR/ACCELERATOR PEDAL POSITION SENSOR
ACCELERATOR PEDAL POSITION SENSOR
B+ GND
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA
COMPUTER DATA LINES SYSTEM
EVAP CANISTER VENT CONTROL VALVE
FUSE 22
FUSE 49
FUSE 50
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY-1 ENERGIZED
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
IGN SW
INTAKE MANIFOLD RUNNER CONTROL VALVE MOTOR
LINES SYSTEM
LT GRN WIRE
ORG/ WIRE
ORG/BLU WIRE
PNK WIRE
PPL
RED WIRE
SENSOR 1
SENSOR 2
SHIELD
SHIELD GND
TAN WIRE
U PHASE TERMINAL
V PHASE TERMINAL
VCR MOTOR
VCR MOTOR ROTATION ANGLE SENSOR, VCR CONTROL SHAFT 2 ROTATION ANGLE SENSOR
VCR PWR
W PHASE TERMINAL
W/ INTELLIGENT CRUISE CONTROL
W/O INTELLIGENT CRUISE CONTROL
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (8 of 9) -> VCR MOTOR ROTATION ANGLE SENSOR, VCR CONTROL SHAFT 2 ROTATION ANGLE SENSOR
