Infiniti QX50 II (2017-2024) switch assembly Wiring diagrams
This page contains all the electrical diagrams for the component. switch assembly, in which he is found in the car Infiniti QX50 II (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram switch assembly (1 of 2)
BLK WIRE
BLU WIRE
DIM LAMP
FRONT ROOM/MAP LAMP ASSEMBLY
GRN WIRE
INSTRUMENT ILLUMINATION CIRCUIT
LEFT ACCESSORY PRE-WIRE
LEFT MAP LAMP
LEFT PERSONAL LAMP
LEFT VANITY LAMP
LT BLU WIRE
LT GRN WIRE
MOOD LAMP (RIGHT REAR DOOR)
PNK WIRE
PPL
RED WIRE
RIGHT FRONT FOOT LAMP
RIGHT MAP LAMP
RIGHT PERSONAL LAMP
RIGHT REAR DOOR POCKET LAMP
RIGHT REAR FOOT LAMP
RIGHT REAR INSIDE HANDLE LAMP
RIGHT REAR STEP LAMP
RIGHT VANITY LAMP
ROOM LAMP
SWITCH ASSEMBLY
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit, w/ interior ambient lighting (4 of 4) -> SWITCH ASSEMBLY
Wiring diagram switch assembly (2 of 2)
BLK WIRE
BLU WIRE
DIM LAMP
FRONT ROOM/MAP LAMP ASSEMBLY
GRN WIRE
INSTRUMENT ILLUMINATION CIRCUIT
LEFT ACCESSORY PRE-WIRE
LEFT FRONT FOOT LAMP
LEFT MAP LAMP
LEFT PERSONAL LAMP
LEFT REAR INSIDE HANDLE LAMP
LEFT REAR STEP LAMP
LEFT VANITY LAMP
PNK WIRE
PPL
RED WIRE
RIGHT ACCESSORY PRE-WIRE
RIGHT FRONT FOOT LAMP
RIGHT MAP LAMP
RIGHT PERSONAL LAMP
RIGHT REAR INSIDE HANDLE LAMP
RIGHT REAR STEP LAMP
RIGHT VANITY LAMP
ROOM LAMP
SWITCH ASSEMBLY
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit, w/o interior ambient lighting (3 of 3) -> SWITCH ASSEMBLY
