Wiring diagram sw rel no (1 of 4)
AIR BAG DIAGNOSIS SENSOR UNIT
B+ MOTOR R
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE IND
BRN WIRE
BUCKLE SW LH+
BUZZER
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ELECTRIC PARKING BRAKE CONTROL MODULE
ELECTRIC PARKING BRAKE SWITCH
FUSE 39
FUSE 8
FUSE BLOCK (J/B)
GND MOTOR L
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGN
LEFT FRONT SEAT BELT BUCKLE SWITCH
LEFT SEAT BELT BUCKLE
PNK WIRE
PPL
RED WIRE
SEAT BELT IND
SW APP NC
SW APP NO
SW REL NC
SW REL NO
SW SUP 1
SW SUP 2
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
YEL WIRE
Go to component -> Chime circuit (2 of 2) -> SW REL NO
Wiring diagram sw rel no (2 of 4)
BACKUP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ELECTRIC PARKING BRAKE CONTROL MODULE
ELECTRIC PARKING BRAKE SWITCH
GRN WIRE
GRY WIRE
LH TURN IND
PNK WIRE
PPL
RED WIRE
RH TURN IND
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP (BACK DOOR SIDE)
RIGHT REAR COMBINATION LAMP (BODY SIDE)
STOP
SW APP NC
SW APP NO
SW REL NC
SW REL NO
SW SUP 1
SW SUP 2
TAIL
TAN WIRE
TURN
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 4) -> SW REL NO
Wiring diagram sw rel no (3 of 4)
B+ MOTOR R
BACK DOOR LOCK ASSEMBLY
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
DOOR AJAR SWITCH
ELECTRIC PARKING BRAKE CONTROL MODULE
ELECTRIC PARKING BRAKE SWITCH
ENG OIL PRESS SENS
ENGINE OIL PRESSURE SENSOR
FUSE 2
FUSE 8
FUSE BLOCK (J/B)
GND MOTOR L
GND MOTOR R
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT "C" PILLAR)
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LEFT SEAT BELT BUCKLE
LEFT SEAT BELT BUCKLE SWITCH
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
PWR ECU
RED WIRE
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
RL DOOR SW
RR DOOR SW
SECURITY LED
SENS GND
SENS PWR SPLY
SUPPLEMENTAL RESTRAINTS SYSTEM
SW APP NC
SW APP NO
SW REL NC
SW REL NO
SW SUP 1
SW SUP 2
TAN WIRE
TOP OF TRANSMISSION)
TRUNK SW
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> SW REL NO
Wiring diagram sw rel no (4 of 4)
AUTOMATIC BRAKE HOLD SWITCH
AUTOMATIC BRAKE HOLD SWITCH INDICATOR
B+ MOTOR L
B+ MOTOR R
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CHASSIS CONTROL MODULE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DEMAND LAMP
ELECTRIC PARKING BRAKE CONTROL MODULE
ELECTRIC PARKING BRAKE SWITCH
ELECTRIC PARKING BRAKE SWITCH INDICATOR
FUSE 20
FUSE 5
FUSE 53
FUSE 8
FUSE BLOCK (J/B)
GND MOTOR L
GND MOTOR R
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT PARKING BRAKE ACTUATOR
LH RR LIGHT POSITION
LT BLU WIRE
MOTOR L+
MOTOR R-
PNK WIRE
PPL
RED WIRE
RIGHT PARKING BRAKE ACTUATOR
SMART FET
SW APP NC
SW APP NO
SW REL NC
SW REL NO
SW SUP 1
SW SUP 2
TAN WIRE
V CAN-H
V CAN-L
WHT WIRE
YEL WIRE
Go to component -> Park brake release circuit -> SW REL NO
