Infiniti QX50 II (2017-2024) sow lamp Wiring diagram
This page shows the only wiring diagram for the component.sow lamp, which is found in the car Infiniti QX50 II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sow lamp (1 of 1)
ADAS CONTROL UNIT (BASE OF LEFT "D" PILLAR)
ADAS CONTROL UNIT 2 (LEFT REAR SEAT)
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
CONFIG
DC MOTOR +
DRIVER ASSISTANCE BUZZER
FRONT CAMERA UNIT
FUSE 27
FUSE BLOCK (J/B)
GND SOW LAMP
GRN WIRE
GRY WIRE
HOT W/ IGNITION RELAY-2 ENERGIZED
IC CAN H
IC CAN L
IGN
ITS CAN-H
ITS CAN-L
ITS SWITCH ASSEMBLY (WARNING SYSTEM SWITCH)
LEFT BLIND SPOT WARNING/ BLIND SPOT INTERVENTION INDICATOR
LEFT SIDE RADAR
LKA SW
LT BLU WIRE
LT GRN WIRE
PNK CAN-L WIRE
PNK WIRE
PPL
RED WIRE
RIGHT BLIND SPOT WARNING/ BLIND SPOT INTERVENTION INDICATOR
RIGHT SIDE RADAR (BASE OF RIGHT "D" PILLAR)
SAFETY SW
SAFETY SW LED
SIGNAL
SIGNAL GND
SOW LAMP
STEERING COLUMN ASSEMBLY
STEERING VIBRATION MOTOR
V CAN-H
V CAN-L
W/ PROPILOT ASSIST
WHT WIRE
YEL WIRE
Go to component -> Driver assistance system circuit -> SOW LAMP
