Infiniti QX50 II (2017-2024) slide open sw Wiring diagram
This page shows the only wiring diagram for the component.slide open sw, which is found in the car Infiniti QX50 II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram slide open sw (1 of 1)
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CIRCUIT BREAKER 1
CLOSE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 2
FUSE 20
FUSE 38
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK I
GRY WIRE
HOT AT ALL TIMES
IGN
LEFT FRONT DOOR SWITCH
LT BLU WIRE
LT GRN WIRE
MOONROOF MOTOR ASSEMBLY (FRONT CENTER OF HEADLINER)
MOONROOF SWITCH
PNK WIRE
POWER WINDOW RELAY
PPL
PUSH SWITCH
PWR ECU
RED WIRE
RIGHT FRONT DOOR SWITCH
SHORTING PIN
SLIDE CLOSE SW
SLIDE OPEN SW
SPEED
SPEED SENSOR
SUNSHADE MOTOR ASSEMBLY (FRONT CENTER OF HEADLINER)
TILT PUSH SW
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
WL AUTHORIZATION RL
YEL WIRE
Go to component -> Power top/sunroof circuit -> SLIDE OPEN SW
