Infiniti QX50 II (2017-2024) right side curtain air bag module shield Wiring diagram
This page shows the only wiring diagram for the component.right side curtain air bag module shield, which is found in the car Infiniti QX50 II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right side curtain air bag module shield (1 of 1)
A/C COMPRESSOR (MAGNETIC CLUTCH)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
AROUND VIEW MONITOR CONTROL UNIT
BLK WIRE
CONDENSER 1
COOLING FAN CONTROL MODULE
GRY WIRE
IGNITION COIL 1 (W/ POWER TRANSISTOR)
IGNITION COIL 2 (W/ POWER TRANSISTOR)
IGNITION COIL 3 (W/ POWER TRANSISTOR)
IGNITION COIL 4 (W/ POWER TRANSISTOR)
INPUT SPEED SENSOR
LEFT REAR SIDE AIR BAG SATELLITE SENSOR SHIELD
LEFT SIDE CURTAIN AIR BAG MODULE SHIELD
NCA WIRE
OUTPUT SPEED SENSOR
PRIMARY SPEED SENSOR
REAR WINDOW DEFOGGER
RIGHT CLIMATE CONTROLLED SEAT BLOWER UNIT
RIGHT FRONT SEAT HEATER
RIGHT LUMBAR SUPPORT SWITCH
RIGHT POWER SEAT SWITCH
RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SEAT BELT BUCKLE SWITCH
RIGHT REAR SIDE AIR BAG SATELLITE SENSOR SHIELD
RIGHT SIDE CURTAIN AIR BAG MODULE SHIELD
SHIELD
STEERING ANGLE MAIN CONTROL MODULE
STEERING FORCE CONTROL MODULE
TCM (TRANSMISSION CONTROL MODULE)
W/ PROPILOT ASSIST
WHT WIRE
Go to component -> Ground distribution circuit (6 of 6) -> RIGHT SIDE CURTAIN AIR BAG MODULE SHIELD
