Infiniti QX50 II (2017-2024) right climate controlled seat blower unit Wiring diagrams
This page contains all the electrical diagrams for the component. right climate controlled seat blower unit, in which he is found in the car Infiniti QX50 II (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
right climate controlled seat blower unit wiring diagram (1 of 2)
A/C AUTO AMPLIFIER (RIGHT SIDE OF DASH)
AUTO ACC
BLK WIRE
BLU WIRE
CAN L
CAN-H
CCS (GND)
CCS (IGN)
CCS (LIN)
CLIMATE CONTROLLED SEAT RELAY
COMPUTER DATA LINES SYSTEM
FUSE 22
FUSE 32
FUSE 37
FUSE 55
FUSE BLOCK (J/B)
GRN WIRE
HEAT SENSOR
HEATER
HEATER (IGN)
HEATER (NTC-IN)
HEATER (NTC-OUT)
HEATER/CCS (GND)
HOT W/ ACCESSORY RELAY-1 ENERGIZED
HOT W/ IGNITION RELAY-2 ENERGIZED
HTR SEAT DR GND
LEFT CLIMATE CONTROLLED SEAT BLOWER UNIT
LEFT FRONT SEAT HEATER (LEFT FRONT SEAT CUSHION)
LEFT SEAT BACK HEATER
LEFT SEAT CUSHION HEATER
MAIN
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RIGHT CLIMATE CONTROLLED SEAT BLOWER UNIT
RIGHT FRONT SEAT HEATER (RIGHT FRONT SEAT CUSHION)
RIGHT SEAT BACK HEATER
RIGHT SEAT CUSHION HEATER
SUB HEATER
WHT WIRE
YEL WIRE
Go to component -> Climate control seats circuit -> RIGHT CLIMATE CONTROLLED SEAT BLOWER UNIT
right climate controlled seat blower unit wiring diagram (2 of 2)
A/C COMPRESSOR (MAGNETIC CLUTCH)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
AROUND VIEW MONITOR CONTROL UNIT
BLK WIRE
CONDENSER 1
COOLING FAN CONTROL MODULE
GRY WIRE
IGNITION COIL 1 (W/ POWER TRANSISTOR)
IGNITION COIL 2 (W/ POWER TRANSISTOR)
IGNITION COIL 3 (W/ POWER TRANSISTOR)
IGNITION COIL 4 (W/ POWER TRANSISTOR)
INPUT SPEED SENSOR
LEFT REAR SIDE AIR BAG SATELLITE SENSOR SHIELD
LEFT SIDE CURTAIN AIR BAG MODULE SHIELD
NCA WIRE
OUTPUT SPEED SENSOR
PRIMARY SPEED SENSOR
REAR WINDOW DEFOGGER
RIGHT CLIMATE CONTROLLED SEAT BLOWER UNIT
RIGHT FRONT SEAT HEATER
RIGHT LUMBAR SUPPORT SWITCH
RIGHT POWER SEAT SWITCH
RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SEAT BELT BUCKLE SWITCH
RIGHT REAR SIDE AIR BAG SATELLITE SENSOR SHIELD
RIGHT SIDE CURTAIN AIR BAG MODULE SHIELD
SHIELD
STEERING ANGLE MAIN CONTROL MODULE
STEERING FORCE CONTROL MODULE
TCM (TRANSMISSION CONTROL MODULE)
W/ PROPILOT ASSIST
WHT WIRE
Go to component -> Ground distribution circuit (6 of 6) -> RIGHT CLIMATE CONTROLLED SEAT BLOWER UNIT
