Infiniti QX50 II (2017-2024) pwr door lock 1 Wiring diagrams

AUTOMATIC BACK DOOR WARNING BUZZER BACK DOOR LOCK ASSEMBLY BACK DOOR OPEN SW BACK DOOR OPENER SWITCH BLK WIRE BLU WIRE BRN WIRE BUTTON SW CAN L CAN-H CINCH LATCH MOTOR CLOSE SWITCH COMPUTER DATA LINES SYSTEM DOOR AJAR SWITCH FUSE 11 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HALF SWITCH HOT AT ALL TIMES LEFT TOUCH SENSOR LT GRN WIRE MOTION ACTIVATED BACK DOOR CONTROL UNIT MOTION ACTIVATED BACK DOOR SENSOR (LOWER) MOTION ACTIVATED BACK DOOR SENSOR (UPPER) OPEN SWITCH OPENER PBD KICK SIGNAL PPL PWR PWR DOOR LOCK 1 RED WIRE REQUEST RIGHT TOUCH SENSOR SENS IN SENS OUT SERIAL SES BACKDOOR SWITCH TGATE SW WHT WIRE

AIR CONDITIONING SYSTEM ANTI-THEFT SYSTEM ANTI-THEFT SYSTEMS AS LOCK OR UNLOCK D AUTOLIGHT SENSOR BCM (BODY CONTROL MODULE) (LEFT SIDE OF DASH) BLK WIRE BLU WIRE BRAKE SW 1 BRAKE SW 2 BRN WIRE BUZZER CAN L CAN-H COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DEFROSTER RL D DI FR LEFT D DI FR LEFT E DI FR RIGHT D DI FR RIGHT E DONGLE UART DOOR LOCK SW DOOR LOCKS DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR UNLOCK SW DR OR FR LOCK D FR OR DR UNLOCK D FUSE 10 FUSE 11 FUSE 12 FUSE 14 FUSE 2 FUSE 38 FUSE 49 FUSE BLOCK (J/B) GND 2 GND AUTOLIGHT SENSOR GRN WIRE GRY WIRE HAZARD SW D HOT AT ALL TIMES I CSW 5 INSTRUMENT CLUSTER SYSTEM LIN 1 D LT BLU WIRE LT GRN WIRE O CSW 1 O CSW 2 O CSW 3 O CSW 4 O CSW 5 O CSW 6 PNK WIRE POWER DISTRIBUTION SYSTEM POWER WINDOWS SYSTEM PPL PWM ROOM LAMP 1 PWM ROOM LAMP 2 PWR ATDVC PWR AUTOLIGHT SENSOR PWR DOOR LOCK 1 PWR DOOR LOCK 2 PWR ECU PWR FLASHERS PWR STOP LAMP PWR WIPER RED WIRE ROOM LAMP BAT SAVER RL SECURITY LED SHIFT INTERLOCK SYSTEM STARTING/CHARGING SYSTEM STCUT RL TAN WIRE WHT WIRE WIPER/WASHER SYSTEM WL AUTHORIZATION RL YEL WIRE
