Infiniti QX50 II (2017-2024) mem sw 1 Wiring diagram
This page shows the only wiring diagram for the component.mem sw 1, which is found in the car Infiniti QX50 II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mem sw 1 (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DEFOGGER SYSTEM
GRN WIRE
GRY WIRE
LEFT DOOR MIRROR
LT BLU WIRE
LT GRN WIRE
MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH (DOOR MIRROR REMOTE CONTROL SWITCH)
MEM IND 1
MEM IND 2
MEM SW 1
MEM SW 2
MIRROR HEATER
MIRROR SWITCH
NAVIGATION SYSTEM
PNK WIRE
PPL
PPL PNK WIRE
RED WIRE
RIGHT DOOR MIRROR
SEAT MEMORY SWITCH
SELECT SWITCH
SET SW
SHIELD
SIDE CAMERA
TAN WIRE
TURN
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit (2 of 3) -> MEM SW 1
