Infiniti QX50 II (2017-2024) left parking brake actuator Wiring diagram
This page shows the only wiring diagram for the component.left parking brake actuator, which is found in the car Infiniti QX50 II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left parking brake actuator (1 of 1)
AUTOMATIC BRAKE HOLD SWITCH
AUTOMATIC BRAKE HOLD SWITCH INDICATOR
B+ MOTOR L
B+ MOTOR R
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CHASSIS CONTROL MODULE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DEMAND LAMP
ELECTRIC PARKING BRAKE CONTROL MODULE
ELECTRIC PARKING BRAKE SWITCH
ELECTRIC PARKING BRAKE SWITCH INDICATOR
FUSE 20
FUSE 5
FUSE 53
FUSE 8
FUSE BLOCK (J/B)
GND MOTOR L
GND MOTOR R
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT PARKING BRAKE ACTUATOR
LH RR LIGHT POSITION
LT BLU WIRE
MOTOR L+
MOTOR R-
PNK WIRE
PPL
RED WIRE
RIGHT PARKING BRAKE ACTUATOR
SMART FET
SW APP NC
SW APP NO
SW REL NC
SW REL NO
SW SUP 1
SW SUP 2
TAN WIRE
V CAN-H
V CAN-L
WHT WIRE
YEL WIRE
Go to component -> Park brake release circuit -> LEFT PARKING BRAKE ACTUATOR
