Infiniti QX50 II (2017-2024) left lumbar support motor Wiring diagram
This page shows the only wiring diagram for the component.left lumbar support motor, which is found in the car Infiniti QX50 II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left lumbar support motor (1 of 1)
BLK WIRE
BLU WIRE
CIRCUIT BREAKER 1
CIRCUIT BREAKER 2
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK I
HOT AT ALL TIMES
LEFT LUMBAR SUPPORT MOTOR
LEFT LUMBAR SUPPORT SWITCH
POWER DISTRIBUTION SYSTEM
PPL
PPL PPL
RED WIRE
RIGHT LUMBAR SUPPORT MOTOR
RIGHT LUMBAR SUPPORT SWITCH
W/ MEMORY W/O MEMORY
WHT WIRE
YEL WIRE
Go to component -> Lumbar circuit -> LEFT LUMBAR SUPPORT MOTOR
