Infiniti QX50 II (2017-2024) left front door mood lamp Wiring diagram
This page shows the only wiring diagram for the component.left front door mood lamp, which is found in the car Infiniti QX50 II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door mood lamp (1 of 1)
AUTOMATIC BACK DOOR CLOSE SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
GRY WIRE
LEFT FRONT DOOR MOOD LAMP
LEFT FRONT DOOR POCKET LAMP
LEFT FRONT INSIDE HANDLE LAMP
LEFT FRONT OUTSIDE HANDLE ASSEMBLY
LEFT FRONT STEP LAMP
LEFT LUGGAGE ROOM LAMP
LT BLU WIRE
LUGGAGE ROOM LAMP RELAY
MOOD LAMP (CENTER CONSOLE POCKET)
MOOD LAMP (CENTER CONSOLE)
MOOD LAMP (LEFT INSTRUMENT PANEL)
MOOD LAMP (RIGHT INSTRUMENT PANEL)
PPL
RED WIRE
RIGHT FRONT DOOR MOOD LAMP
RIGHT FRONT DOOR POCKET LAMP
RIGHT FRONT INSIDE HANDLE LAMP
RIGHT FRONT OUTSIDE HANDLE ASSEMBLY
RIGHT FRONT STEP LAMP
RIGHT LUGGAGE ROOM LAMP
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit, w/ interior ambient lighting (2 of 4) -> LEFT FRONT DOOR MOOD LAMP
