Infiniti QX50 II (2017-2024) inst right sp+ Wiring diagrams
This page contains all the electrical diagrams for the component. inst right sp+, in which he is found in the car Infiniti QX50 II (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
inst right sp+ wiring diagram (1 of 2)
BLK WIRE
BLU WIRE
BOSE SPEAKER AMP (LEFT REAR CARGO AREA)
BRN WIRE
ENGINE TACH+
FR DOOR LH -
FR DOOR RH -
FUSE 2
FUSE 22
FUSE 42
FUSE 43
FUSE 44
FUSE 45
FUSE 46
FUSE 50
FUSE 55
FUSE 68
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY-1 ENERGIZED
HOT W/ IGNITION 1 RELAY ENERGIZED
HOT W/ IGNITION RELAY-2 ENERGIZED
INST CENTER SP+
INST LEFT SP+
INST RIGHT SP+
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
REAR SUB WOOFER-
RED WIRE
RIGHT FRONT TWEETER
RIGHT LOWER FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT REAR DOOR TWEETER
RR DR SP LH+
RR DR SP RH-
RR PILLAR SP LH+
RR PILLAR SP RH+
SHIELD
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH
WHT WIRE
WOOFER FR LH-
WOOFER FR RH-
YEL WIRE
Go to component -> Navigation circuit, w/ bose (2 of 6) -> INST RIGHT SP+
inst right sp+ wiring diagram (2 of 2)
BLK WIRE
BLU WIRE
BOSE SPEAKER AMP (LEFT REAR CARGO AREA)
BRN WIRE
ENGINE TACH+
FR DOOR LH -
FR DOOR RH -
FUSE 2
FUSE 22
FUSE 42
FUSE 43
FUSE 44
FUSE 45
FUSE 46
FUSE 50
FUSE 55
FUSE 68
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY-1 ENERGIZED
HOT W/ IGNITION 1 RELAY ENERGIZED
HOT W/ IGNITION RELAY-2 ENERGIZED
INST CENTER SP+
INST LEFT SP+
INST RIGHT SP+
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
REAR SUB WOOFER-
RED WIRE
RIGHT FRONT TWEETER
RIGHT LOWER FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT REAR DOOR TWEETER
RR DR SP LH+
RR DR SP RH-
RR PILLAR SP LH+
RR PILLAR SP RH+
SHEILD
SHIELD
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH
WHT WIRE
WOOFER FR LH-
WOOFER FR RH-
YEL WIRE
Go to component -> Radio circuit, w/ bose (2 of 6) -> INST RIGHT SP+
