Infiniti QX50 II (2017-2024) gnd sens gnd Wiring diagram
This page shows the only wiring diagram for the component.gnd sens gnd, which is found in the car Infiniti QX50 II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd sens gnd (1 of 1)
ADP STEERING SWITCH
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
BACKWARD
BAT (PTC)
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
BWD
CAN L
CAN-H
CIRCUIT BREAKER 2
COMPUTER DATA LINES SYSTEM
DOWNWARD
FORWARD/
FUSE 2
FUSE 20
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK I
GND PWR
GND SENS GND
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR SWITCH
LT BLU WIRE
LT GRN WIRE
MIR MTR LH (HORIZ LEFT)
MIR MTR LH COM (DOWN RH)
MIR MTR LH VERT (UP)
MIR MTR RH COM (DOWN RH)
MIR MTR RH HORIZ (LEFT)
MIR MTR RH VERT (UP)
MIR SELECT SW (LH)
MIR SELECT SW (RH)
MIR SENS (LH HORIZ)
MIR SENS (LH VERT)
MIR SENS (RH HORIZ)
MIR SENS (RH VERT)
MIR SW (DOWNWARD)
MIR SW (LEFTWARD)
MIR SW (RIGHTWARD)
MIR SW (UPWARD)
PNK WIRE
PPL
PPL PNK WIRE
PWR ECU
RED WIRE
STRG MTR COM (UP/FWD)
TELESCOPIC MTR (BACKWARD)
TELESCOPIC SW (BACKWARD)
TELESCOPIC SW (FRONTWARD)
TELESCOPIC SWITCH
TILT MTR (DOWNWARD)
TILT SW (DOWNWARD)
TILT SW (UPWARD)
TILT SWITCH
TILT, TELESCOPIC MOTOR (STEERING COLUMN ASSEMBLY)
UART (TX/RX)
UPWARD
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit (1 of 3) -> GND SENS GND
