Infiniti QX50 II (2017-2024) drivetrain can-l drivetrain can-h wiring diagram
This page shows the only wiring diagram for the component.drivetrain can-l drivetrain can-h, which is found in the car Infiniti QX50 II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
drivetrain can-l drivetrain can-h wiring diagram (1 of 1)
ACCELERATOR PEDAL POSITION SENS 1
ACCELERATOR PEDAL POSITION SENS 2
ASCD STEERING SWITCH
BATTERY
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRAKE PEDAL ASSEMBLY)
BRAKE PEDAL POSITION SWITCH
BRK
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
CTRL MODULE
DRIVETRAIN CAN-L DRIVETRAIN CAN-H
ECM (LEFT FRONT OF ENGINE COMPT)
ECM GND
ENGINE SPD SIG
EVAP CANISTER VENT CTRL VALVE
EVAP CONTROL SYSTEM PRESSURE SENSOR
EVAP CTRL SYSTEM PRESS SENS
FPCM
FPCM CHECK
FUEL LEVEL SENSOR UNIT (SUB) FUEL LEVEL SENSOR (MAIN)
FUEL LEVEL SENSOR UNIT, FUEL PUMP (MAIN) (BASE OF LEFT "C" PILLAR)
FUEL PUMP
FUEL PUMP CTRL MODULE (FPCM)
FUEL PUMP CTRL MODULE (FPCM) CHECK
FUEL TANK TEMPERATURE SENS
FUEL TANK TEMPERATURE SENSOR
GND PWR
GRN WIRE
GRY WIRE
IGN
IGNITION SWITCH
INSTRUMENT CLUSTER SYSTEM
LT BLU WIRE
LT GRN WIRE
MALFUNCTION IND LAMP (MIL)
NAVIGATION, SOUND SYSTEMS
ORG/ WIRE
ORG/BLU WIRE
PNK WIRE
PPL
PWR SPLY FOR ECM
RED WIRE
SENS GND
SENS PWR SPLY
STOP LAMP SWITCH
SW 2
TAN WIRE
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (9 of 9) -> DRIVETRAIN CAN-L DRIVETRAIN CAN-H
