Infiniti QX50 II (2017-2024) battery pnk gnd Wiring diagrams

BATTERY PNK GND WIRE BCM (BODY CONTROL MODULE) BETWEEN FULL STROKE, N BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM DOOR LOCK SW DOOR UNLOCK SW FULL STROKE FUSE 13 FUSE 2 FUSE 20 FUSE 40 FUSE BLOCK (J/B) GND 2 GND AUTOLIGHT SENSOR GRY WIRE HOT AT ALL TIMES KEY CYLINDER LOCK SW KEY CYLINDER SWITCH KEY CYLINDER UNLOCK SW LEFT "C" PILLAR) LEFT FRONT DOOR LOCK ASSEMBLY (REAR OF FRONT DOOR) LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LIN 2 D LIN 3 D LOCK LOCK SWITCH LT BLU WIRE LUGGAGE LAMP RL MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH (DOOR MIRROR REMOTE CONTROL SWITCH) PNK LIN 3 D WIRE PNK WIRE PPL PWM ROOMLAMP 2 PWR ECU RED WIRE REMOTE KEYLESS ENTRY RECEIVER RIGHT FRONT DOOR SWITCH RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH RIGHT REAR DOOR SWITCH RL DOOR SW ROOM LAMP RELAY ROOMLAMP BATSAVER RL RR DOOR SW UNLOCK UNLOCK SWITCH WHT WIRE YEL WIRE

BATTERY PNK GND WIRE BCM (BODY CONTROL MODULE) BETWEEN FULL STROKE, N BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM DOOR LOCK SW DOOR UNLOCK SW FULL STROKE FUSE 13 FUSE 2 FUSE 20 FUSE BLOCK (J/B) GND 2 GND AUTOLIGHT SENSOR GRY WIRE HOT AT ALL TIMES KEY CYLINDER LOCK SW KEY CYLINDER SWITCH KEY CYLINDER UNLOCK SW LEFT "C" PILLAR) LEFT FRONT DOOR LOCK ASSEMBLY (REAR OF FRONT DOOR) LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LIN 2 D LIN 3 D LOCK LOCK SWITCH LT BLU WIRE LUGGAGE LAMP RL MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH (DOOR MIRROR REMOTE CONTROL SWITCH) PNK LIN 3 D WIRE PNK WIRE PPL PWM ROOMLAMP 1 PWM ROOMLAMP 2 PWM ROOMLAMP 5 PWR ECU RED WIRE REMOTE KEYLESS ENTRY RECEIVER RIGHT FRONT DOOR SWITCH RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH RIGHT REAR DOOR SWITCH RL DOOR SW ROOM LAMP RELAY ROOMLAMP BATSAVER RL RR DOOR SW UNLOCK UNLOCK SWITCH WHT WIRE YEL WIRE
