Infiniti QX50 II (2017-2024) batt temp sens Wiring diagram
This page shows the only wiring diagram for the component.batt temp sens, which is found in the car Infiniti QX50 II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram batt temp sens (1 of 1)
BATT CURRENT SENS
BATT TEMP SENS
BATTERY
BATTERY CURRENT SENSOR
BATTERY TEMPERATURE SENSOR
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ENGINE CONTROLS SYSTEM
EXTENDED STORAGE SWITCH
FUSE 39
FUSE 50
FUSE BLOCK (J/B)
FUSIBLE LINK A
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK F
GENERATOR
GND 2
GRN WIRE
GRY WIRE
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
LT BLU WIRE
NCA WIRE
PNK WIRE
PPL
RED WIRE
SENS GND
SENS PWR SPLY
STARTER MOTOR
TOP OF TRANSMISSION)
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
Go to component -> Charging circuit -> BATT TEMP SENS
