Infiniti QX50 II (2017-2024) adas control unit 2 shield Wiring diagram
This page shows the only wiring diagram for the component.adas control unit 2 shield, which is found in the car Infiniti QX50 II (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram adas control unit 2 shield (1 of 1)
ADAS CONTROL UNIT 2
ADAS CONTROL UNIT 2 SHIELD
AUTO ANTI-DAZZLING INSIDE MIRROR
AUTOMATIC BACK DOOR CLOSE SWITCH
BACK DOOR LOCK ASSEMBLY (DOOR AJAR SWITCH)
BCM (BODY CONTROL MODULE)
BLK WIRE
DATA LINK CONNECTOR
DRIVE MODE SWITCH
ELECTRIC PARKING BRAKE SWITCH
ELECTRIC SHIFT SELECTOR
FRONT AUXILIARY INPUT JACKS CONTROL UNIT
HIGH MOUNTED STOP LAMP
ITS SWITCH ASSEMBLY
LEFT BLIND SPOT WARNING/ BLIND SPOT INTERVENTION INDICATOR
LEFT DOOR MIRROR
LEFT FRONT OUTSIDE HANDLE ASSEMBLY
LEFT LUGGAGE ROOM LAMP
LEFT REAR COMBINATION LAMP (BACK DOOR SIDE)
LEFT REAR COMBINATION LAMP (BODY SIDE)
LEFT SIDE RADAR
MOONROOF MOTOR ASSEMBLY
REAR WIPER MOTOR
SEAT MEMORY SWITCH
STEERING ANGLE SENSOR
SUNSHADE MOTOR ASSEMBLY
TRAILER CONNECTOR
TRAILER LAMP CONVERTER MODULE
W/ MOONROOF
WHT WIRE
Go to component -> Ground distribution circuit (1 of 6) -> ADAS CONTROL UNIT 2 SHIELD
