Electronic power steering circuit for Infiniti QX50 I (2013-2015)

1 2 3 4 5 6 7 8 9 10 11 12 EPS SOL+ 1 2 CAN-H CAN-L PNK WIRE BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ENG SPEED OUTPUT SIG ENG TACHO ENGINE CONTROL MODULE (ECM) (RIGHT END OF DASH) EPS SOL GND FUSE 45 GRN WIRE HOT IN ON OR START IGN LT GRN WIRE POWER STEERING CONTROL UNIT (RIGHT SIDE OF DASH) RED WIRE STEERING ANGLE SENSOR (ON STEERING COLUMN) UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER CONSOLE) VSP
