Courtesy lamps circuit for Infiniti QX4 I (1996-2003)

BACK DOOR SWITCH BLK WIRE BLU WIRE DIODE (LUGGAGE ROOM LAMP) DOOR FUSE 11 FUSE 24 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) GRN WIRE GRN/RED WIRE HOT AT ALL TIMES HOT IN ON OR START INTERIOR LAMP DOOR OFF ON KEY SWITCH LEFT FRONT DOOR LOCK ACTUATOR (DOOR UNLOCK SENSOR) LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LEFT VANITY MIRROR LUGGAGE ROOM LAMP ON OFF RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH RIGHT VANITY MIRROR SMART ENTRANCE CONTROL UNIT (BEHIND DASH, NEXT TO FUSE BLOCK) SPOT LAMP WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE
