Infiniti QX4 I (1996-2003) wash sw ppl 2 3 4 5 lo sw hatch sw int sw Wiring diagram
This page shows the only wiring diagram for the component.wash sw ppl 2 3 4 5 lo sw hatch sw int sw, which is found in the car Infiniti QX4 I (1996-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wash sw ppl 2 3 4 5 lo sw hatch sw int sw (1 of 1)
AUTO-STOP
BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMBINATION SWITCH (REAR WIPER SWITCH)
FUSE 29
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
GLASS HATCH SWITCH
GRN/ORG WIRE
GRN/WHT WIRE
HOT IN ACC OR ON
LT GRN WIRE
LT GRN/BLK WIRE
PNK/BLU WIRE
PNK/GRN WIRE
REAR WASHER MOTOR (ON WASHER FLUID RESERVOIR)
REAR WIPER AMPLIFIER
REAR WIPER MOTOR (ON LOWER RIGHT SIDE OF HATCH)
RED WIRE
RED/BLK WIRE
WASH MTR WIPER (-) GROUND WIPER E
WASH OFF 21 22 INT PPL ON WASH
WASH OFF INT ON WASH
WASH SW PPL 2 3 4 5 LO SW HATCH SW INT SW
WHT WIRE
WHT/BLK WIRE
WIPER
Go to component -> Rear washer/wiper circuit -> WASH SW PPL 2 3 4 5 LO SW HATCH SW INT SW
