Infiniti QX4 I (1996-2003) spot lamp Wiring diagram
This page shows the only wiring diagram for the component.spot lamp, which is found in the car Infiniti QX4 I (1996-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram spot lamp (1 of 1)
BACK DOOR SWITCH
BLK WIRE
BLU WIRE
DIODE (LUGGAGE ROOM LAMP)
DOOR
FUSE 11
FUSE 24
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INTERIOR LAMP DOOR OFF ON
KEY SWITCH
LEFT FRONT DOOR LOCK ACTUATOR (DOOR UNLOCK SENSOR)
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LEFT VANITY MIRROR
LUGGAGE ROOM LAMP
ON OFF
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
RIGHT VANITY MIRROR
SMART ENTRANCE CONTROL UNIT (BEHIND DASH, NEXT TO FUSE BLOCK)
SPOT LAMP
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Courtesy lamps circuit -> SPOT LAMP
