Infiniti QX4 I (1996-2003) back door key cylinder switch Wiring diagrams

BACK DOOR BACK DOOR KEY CYLINDER SWITCH BACK DOOR LOCK ACTUATOR BLK WIRE FULL STROKE LOCK FULL STROKE UNLOCK GLASS HATCH GRN/BLK WIRE LEFT FRONT DOOR KEY CYLINDER SWITCH LEFT FRONT DOOR LOCK ACTUATOR LEFT REAR DOOR LOCK ACTUATOR LOCK UNLOCK LOCKED LT GRN WIRE MID STROKE RIGHT FRONT DOOR LOCK ACTUATOR RIGHT REAR DOOR LOCK ACTUATOR UNLOCKED YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/PPL WIRE YEL/RED WIRE

BACK DOOR KEY CYLINDER SWITCH BACK DOOR LOCK ACTUATOR BETWEEN LOCK FULL STROKE AND N FULL STROKE BLK WIRE BLU WIRE BRN WIRE CIRCUIT BREAKER (ON TOP OF FUSE BLOCK) FULL STROKE BETWEEN FULL STROKE AND N UNLOCK FUSE 24 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) GRN WIRE GRN/RED WIRE HOT AT ALL TIMES KEY SWITCH LEFT FRONT DOOR KEY CYLINDER SWITCH LEFT FRONT DOOR LOCK ACTUATOR LEFT FRONT DOOR SWITCH BACK DOOR SWITCH LEFT REAR DOOR LOCK ACTUATOR LEFT REAR DOOR SWITCH LOCK LOCKED LT GRN WIRE LT GRN/RED WIRE MAIN POWER WINDOW, DOOR LOCK SWITCH OUT IN RED WIRE RED/BLK WIRE RED/BLU WIRE RIGHT FRONT DOOR LOCK ACTUATOR RIGHT FRONT DOOR SWITCH RIGHT FRONT POWER WINDOW, DOOR LOCK SWITCH RIGHT REAR DOOR LOCK ACTUATOR RIGHT REAR DOOR SWITCH SMART ENTRANCE CONTROL UNIT (BEHIND DASH, NEXT TO FUSE BLOCK) UNLOCK UNLOCKED WHT WIRE WHT/PPL WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/PPL WIRE YEL/RED WIRE
