Car Wiring Diagrams for Cruise control circuit for Infiniti Q60 II (2016-2024)

ACCELERATOR PDL POSITION SENS 1 ACCELERATOR PDL POSITION SENS 2 ACCELERATOR PEDAL POSITION SENSOR ASCD STEERING SW SENS GND (ASCD STEERING SW) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM FUSE 46 FUSE 63 FUSE 64 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ECM RELAY ENERGIZED IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT BLU WIRE LT GRN WIRE MULTI-WAY CTRL VALVE PWR SPLY PNK WIRE PPL PWR SPLY RED WIRE SENS GND SENS PWR SPLY SENSOR 1 SENSOR 2 SHIELD TAN WIRE THROTTLE CONTROL MOTOR (CLOSE) (BANK 1) THROTTLE CONTROL MOTOR (OPEN) (BANK 1) THROTTLE CONTROL MOTOR (OPEN) (BANK 2) THROTTLE CONTROL MOTOR RELAY THROTTLE MTR PWR SPLY THROTTLE MTR RLY WHT WIRE YEL WIRE

A/T ASSEMBLY ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) ACCELERATE/ RESUME SWITCH ASCD STEERING SWITCH BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CLOSE COAST/ SET SWITCH CANCEL SWITCH COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM FUSE 19 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES INPUT SPEED SENSOR 1 INPUT SPEED SENSOR 2 JOINT CONNECTOR LT BLU WIRE LT GRN WIRE MAIN (ON/ OFF) SWITCH NCA WIRE OUTPUT SPEED SENSOR PNK WIRE PPL RED WIRE SENSOR 1 SENSOR 2 SHIELD STOP LAMP SWITCH STOP LP SW SIG TAN WIRE TCM THROTTLE CONTROL MOTOR THROTTLE POSITION SENSOR TRANSMISSION RANGE SWITCH WHT WIRE YEL WIRE
