Computer data lines circuit, w/o telematics for Infiniti Q60 II (2016-2024)

Computer data lines circuit, w/o telematics (1 of 4)

Q60 Infiniti II (2016-2024): Computer data lines circuit, w/o telematics (1 of 4)

Get access

ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) ACTIVE NOISE CONTROL UNIT BATT PWR SPLY BLK WIRE BLU WIRE CAN L CAN-H DATA LINK CONNECTOR DIAGNOSTIC CAN COMM H DIAGNOSTIC CAN COMM L FUSE 12 FUSE 14 FUSE 17 FUSE 4 FUSE BLOCK (J/B) HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED IGN PWR SPLY IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) IT CAN COMM H IT CAN COMM L K LINE LT BLU WIRE LT GRN WIRE NCA WIRE OCCUPANT DETECTION SYSTEM CONTROL UNIT PNK WIRE PPL RED WIRE SHIELD VEHICLE CAN COMM 1 H VEHICLE CAN COMM 1 L W/O BOSE W/O FORWARD EMERGENCY BRAKING WHT WIRE YEL WIRE

Computer data lines circuit, w/o telematics (2 of 4)

Q60 Infiniti II (2016-2024): Computer data lines circuit, w/o telematics (2 of 4)

Get access

A/T ASSEMBLY ADAS CONTROL UNIT AIR BAG DIAGNOSIS SENSOR UNIT BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE CAN L CAN-H CHASSIS COMM-H CHASSIS COMM-L DRIVER SEAT CONTROL UNIT DRIVER SIDE FRONT SEAT ELECTRIC INTAKE VALVE TIMING CONTROL MODULE ITS COMM-H ITS COMM-L J/C LINE-H LINE-L LT BLU WIRE NCA WIRE PNK WIRE POWER STEERING CONTROL MODULE PPL RED WIRE SHIELD STEERING ANGLE SENSOR STEERING COLUMN ASSEMBLY TCM W/O FORWARD EMERGENCY BRAKING YEL WIRE

Computer data lines circuit, w/o telematics (3 of 4)

Q60 Infiniti II (2016-2024): Computer data lines circuit, w/o telematics (3 of 4)

Get access

A/C AUTO AMPLIFIER ADAS CONTROL UNIT 2 AV COMM SIG (H) AV COMM SIG (L) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CHASSIS COMM-H CHASSIS COMM-L DISPLAY CONTROL UNIT ITS COMM-H ITS COMM-L LANE CAMERA UNIT LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE SHIELD WHT WIRE YEL WIRE

Computer data lines circuit, w/o telematics (4 of 4)

Q60 Infiniti II (2016-2024): Computer data lines circuit, w/o telematics (4 of 4)

Get access

ACCELERATOR PEDAL ACTUATOR/ ACCELERATOR PEDAL POSITION SENSOR AROUND VIEW MONITOR CONTROL UNIT AV COMM (H) AV COMM (L) AV COMM SIG (H) AV COMM SIG (L) AV COMM-GND AV CONTROL UNIT BLK WIRE BLU WIRE BOSE AMP CAN L CAN-H COMBINATION METER DISTANCE SENSOR INTEGRAL SWITCH ITS COMM SIG-H ITS COMM SIG-L LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE SHIELD WHT WIRE YEL WIRE
