Infiniti Q60 I (2013-2016) trunk status sensor Wiring diagram
This page shows the only wiring diagram for the component.trunk status sensor, which is found in the car Infiniti Q60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk status sensor (1 of 1)
BEHIND REAR SEATS)
BLK WIRE
BLU WIRE
BRN WIRE
FLIPPER DOOR RELAY (DOWN)
FLIPPER DOOR RELAY (UP)
GRN WIRE
GRY WIRE
HYDRAULIC PUMP MOTOR
HYDRAULIC PUMP POWER SUPPLY RELAY
HYDRAULIC UNIT (BEHIND LEFT REAR WHEELWELL)
LEFT FLIPPER DOOR
LEFT FLIPPER DOOR LIMIT SWITCH (DOWN)
LEFT FLIPPER DOOR LIMIT SWITCH (UP)
LEFT FLIPPER DOOR MOTOR
LEFT HYDRAULIC PUMP RELAY
LEFT TRUNK LINK SENSOR (BEHIND LEFT REAR WHEELWELL)
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK 11 12 WIRE
PNK 5 6 7 8 9 WIRE
PNK WIRE
PPL
RED WIRE
RIGHT FLIPPER DOOR
RIGHT FLIPPER DOOR LIMIT SWITCH (DOWN)
RIGHT FLIPPER DOOR LIMIT SWITCH (UP)
RIGHT FLIPPER DOOR MOTOR
RIGHT HYDRAULIC PUMP RELAY
RIGHT TRUNK LINK SENSOR (BEHIND RIGHT REAR WHEELWELL)
SWITCHING SWITCHING VALVE 2 VALVE 1
TAN WIRE
TRUNK STATUS SENSOR
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit, convertible (3 of 3) -> TRUNK STATUS SENSOR
