Infiniti Q60 I (2013-2016) down front lifting switch up Wiring diagram
This page shows the only wiring diagram for the component.down front lifting switch up, which is found in the car Infiniti Q60 I (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram down front lifting switch up (1 of 1)
BACKWARD
BACKWARD RECLINING SWITCH
BAT (C/B)
BAT FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BUCKLE SW
BWD
CAN L
CAN-H
CIRCUIT BREAKER (BEHIND CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
CONVERTIBLE COUPE
DOWN
DOWN FRONT LIFTING SWITCH UP
DOWN REAR LIFTING SWITCH UP
DRIVER SEAT CONTROL UNIT
DRIVER SIDE DOOR SWITCH
DRIVER SIDE FRONT SEAT
DRIVER SIDE SEAT BELT BUCKLE SWITCH (IN DRIVER SEAT BELT BUCKLE ASSEMBLY)
FORWARD SW
FORWARD SWITCH
FORWARD/
FRONT LIFTING MOTOR
FRT LIFTING MTR (DWD)
FRT LIFTING MTR (UWD)
FRT LIFTING SW (DWD)
FRT LIFTING SW (UWD)
FUSE 10
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK K
GND PWR
GND SIG
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN/RED WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK FWD WIRE
PNK WIRE
PNK/BLU WIRE
POWER SEAT SWITCH
POWER WALK-IN SW
POWER WALK-IN SWITCH
PPL
PULSE (SLIDING)
REAR LIFTING MOTOR
REAR LIFTING MTR (DWD)
REAR LIFTING MTR (UWD)
REAR LIFTING SW (DWD)
REAR LIFTING SW (UWD)
RECLINING MOTOR
RECLINING MTR BWD
RECLINING MTR FWD
RECLINING SW BWD
RECLINING SW FWD
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SENS GND
SLIDING LIMIT SW
SLIDING LIMIT SWITCH
SLIDING MOTOR
SLIDING MTR (BWD)
SLIDING MTR (FWD)
SLIDING SENSOR
SLIDING SW (BWD)
SLIDING SW (FWD)
SLIDING SWITCH
VCC
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power seats circuit (1 of 2) -> DOWN FRONT LIFTING SWITCH UP
