Horn circuit for Infiniti Q45 III (2001-2006)
Horn circuit
BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL)
COMBINATION SWITCH (SPIRAL CABLE)
FUSE 56
FUSE, FUSIBLE LINK, RELAY BLOCK (J/B) (IN ENGINE ROOM BOX)
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
HIGH HORN (LEFT FRONT OF ENGINE COMPT)
HORN CHRP
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES
JOINT CONNECTOR 25 (BEHIND LEFT KICK PANEL, TAPED TO HARNESS)
LOW HORN (AT RIGHT FRONT RADIATOR SUPPORT)
RED WIRE
