Warning system circuits for Infiniti Q45 I (1989-1996)

A-9 A-11 AIRBAG CONTROL UNIT B-23 BLK WIRE BLK/WHT WIRE BLU WIRE BODY COMPUTER MODULE (BEHIND LEFT SIDE OF I/P) BRN WIRE CHIME DETENTION SWITCH FUSE 19 FUSE 25 FUSE 37 FUSE 38 FUSE BLOCK FUSE, FUSIBLE LINK BOX GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE HEADLAMP RELAY UNIT (RIGHT FRONT OF ENGINE COMPT) HOT AT ALL TIMES HOT IN ON OR START ILLUMINATION CONTROL SWITCH INSTRUMENT CLUSTER J/C 2 J/C 5 (LEFT SIDE OF I/P) KEY SWITCH LEFT FRONT DOOR SWITCH LEFT FRONT POWER SEAT CONTROL UNIT (BELOW LEFT FRONT SEAT) LIGHT SWITCH NCA WIRE OFF PARK HEAD LO BEAM HI BEAM FLASH- TO-PASS 1 2 3 4 5 6 ORG/ WIRE PPL PPL DATA LINES PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE SEAT BELT SWITCH SHIFT LOCK CONTROL UNIT WHT WIRE YEL WIRE YEL/ORG WIRE
