Infiniti Q45 I (1989-1996) Drl circuit

BLK WIRE BLK/BLU WIRE BLU WIRE BLU/RED WIRE BODY COMPUTER MODULE DIAGNOSTIC INFORMATION DISPLAY DIAGNOSTIC INFORMATION DISPLAY CONTROL UNIT DIODE (LEFT SIDE OF I/P) FUSE 31 FUSE 32 FUSE 37 FUSE, FUSIBLE LINK BOX GRN WIRE GRN/RED WIRE HEADLAMP RELAY UNIT (RIGHT FRONT OF ENGINE COMPARTMENT) HEADLAMP SENSOR HEADLAMP SENSOR (BEHIND LEFT SIDE OF I/P) HEADLAMPS ON HI LO HI-BEAM IND HOT AT ALL TIMES INSTRUMENT CLUSTER J/C 1 (RIGHT FRONT OF ENGINE COMPT) J/C-2 (BEHIND RIGHT HEADLAMP) J/C-5 (LEFT I/P) J/C-6 (LEFT I/P) LEFT DUAL BEAM HEAD- LAMP LEFT HI BEAM HEAD- LAMP LIGHT SWITCH LO HI OFF PARK HEAD LO BEAM HI BEAM FLASH- TO-PASS 1 2 3 4 5 6 ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT DUAL BEAM HEAD- RIGHT HI BEAM HEAD- LAMP THEFT WARNING RELAY-1 WHT WIRE YEL WIRE YEL/BLK WIRE

ALTERNATOR BLK WIRE BLK/BLU WIRE BLU WIRE BLU/BLK WIRE DAYTIME LIGHT CANCEL RELAY (LEFT FRONT ENGINE COMPT) DAYTIME LIGHT CONTROL UNIT (BELOW RIGHT HEADLAMP) DIODE (LEFT I/P) FUSE 13 FUSE 40 FUSE BLOCK FUSE, FUSIBLE LINK BOX GRN WIRE HOT IN ON OR START HOT IN START J/C-1 (RIGHT FRONT ENGINE COMPT) J/C-1 (RIGHT I/P) J/C-6 (LEFT I/P) J/C-6 (RIGHT I/P) LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE PARKING BRAKE SWITCH (LEFT I/P) RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE WHT WIRE WHT/RED WIRE YEL WIRE
