Car Wiring Diagrams for Charging circuit for Infiniti M56 IV (2010-2013)

39 40 PNK WIRE ALTERNATOR BATTERY BATTERY TERMINAL FUSIBLE W/ FUSIBLE LINK LINK A BLK WIRE BLU WIRE BRN WIRE CHARGE IND COMBINATION METER COMPUTER DATA LINES SYSTEM FUSE 4 FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH) FUSE, FUSE FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK C GRN WIRE GRY WIRE HOT W/ IGNITION RELAY ENERGIZED NCA WIRE PCB HARNESS PNK WIRE RED WIRE TAN WIRE WHT WIRE
