Infiniti M56 IV (2010-2013) trunk room lamp Wiring diagram
This page shows the only wiring diagram for the component.trunk room lamp, which is found in the car Infiniti M56 IV (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk room lamp (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
DIODE
DOOR
DOOR OFF
DRIVER SIDE STEP LAMP
DRIVER SIDE VANITY MIRROR LAMP
GRN WIRE
LEFT
LEFT FRONT OUTSIDE HANDLE ASSEMBLY
LEFT REAR STEP LAMP
LT BLU WIRE
LT GRN WIRE
MAP LAMP
OFF
ORG/ WIRE
PASSENGER SIDE STEP LAMP
PASSENGER SIDE VANITY MIRROR LAMP
PCB HARNESS
PERSONAL LAMP
PPL
PPL PPL
RED WIRE
RIGHT
RIGHT FRONT OUTSIDE HANDLE ASSEMBLY
RIGHT REAR STEP LAMP
TRUNK LID LOCK ASSEMBLY
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> TRUNK ROOM LAMP
