Infiniti M56 IV (2010-2013) ppl sensor ground refrigerant pressure sensor Wiring diagrams
This page contains all the electrical diagrams for the component. ppl sensor ground refrigerant pressure sensor, in which he is found in the car Infiniti M56 IV (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ppl sensor ground refrigerant pressure sensor (1 of 2)
1 2 3 PPL
146 151 COMM LINE COMM LINE
A/C RELAY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN CONTROL MODULE 1 (BEHIND LEFT SIDE OF RADIATOR)
COOLING FAN CONTROL MODULE 2 (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN MOTOR 1 (BEHIND LEFT SIDE OF RADIATOR)
COOLING FAN MOTOR 2 (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN RELAY 1 (IN FUSE,FUSIBLE LINK, RELAY BOX)
COOLING FAN RELAY 2 (IN FUSIBLE LINK HOLDER)
ENGINE CONTROL MODULE (ECM) (RIGHT REAR OF ENGINE COMPT)
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR (RIGHT REAR OF ENGINE)
FUSE 42
FUSE 49
FUSIBLE LINK HOLDER (RIGHT SIDE OF ENGINE COMPT)
FUSIBLE LINK HOLDER 1
FUSIBLE LINK HOLDER 2
FUSIBLE LINK O
FUSIBLE LINK R
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION RELAY
LT GRN WIRE
NCA WIRE
PCB HARNESS
PNK WIRE
PPL
PPL PNK PPL WIRE
PPL SENSOR GROUND REFRIGERANT PRESSURE SENSOR
RED WIRE
REFRIGERANT PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPT)
SENSOR GROUND
SENSOR POWER SUPPLY
TAN WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (4 of 4) -> PPL SENSOR GROUND REFRIGERANT PRESSURE SENSOR
Wiring diagram ppl sensor ground refrigerant pressure sensor (2 of 2)
1 2 3 PPL
146 151 CAN COMM LINE CAN COMM LINE PNK WIRE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN CONTROL MODULE 1 (BEHIND LEFT SIDE OF RADIATOR)
COOLING FAN CONTROL MODULE 2
COOLING FAN MOTOR 1 (BEHIND LEFT SIDE OF RADIATOR)
COOLING FAN MOTOR 2 (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN RELAY 1 (IN FUSE, FUSIBLE LINK, RELAY BOX)
COOLING FAN RELAY 2 (IN FUSIBLE LINK HOLDER)
ENGINE CONTROL MODULE (ECM) (RIGHT REAR OF ENGINE COMPT)
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR (RIGHT REAR OF ENGINE)
FUSE 42
FUSIBLE LINK D
FUSIBLE LINK HOLDER (RIGHT SIDE OF ENGINE COMPT)
FUSIBLE LINK HOLDER 1
FUSIBLE LINK O
FUSIBLE LINK R
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSIBLE LINK HOLDER 2
IGNITION RELAY
LT GRN WIRE
NCA WIRE
PCB HARNESS
PNK WIRE
PPL
PPL PPL
PPL SENSOR GROUND REFRIGERANT PRESSURE SENSOR
RED WIRE
REFRIGERANT PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPT)
SENSOR GROUND
SENSOR POWER SUPPLY
TAN WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> PPL SENSOR GROUND REFRIGERANT PRESSURE SENSOR
