Infiniti M56 IV (2010-2013) multifunction switch Wiring diagram
This page shows the only wiring diagram for the component.multifunction switch, which is found in the car Infiniti M56 IV (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram multifunction switch (1 of 1)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
COMBINATION SWITCH (SPIRAL CABLE)
CRASH ZONE SENSOR
DRIVER AIR BAG MODULE
GRN WIRE
GRY WIRE
LEFT FRONT DOOR SATELLITE SENSOR
LT BLU WIRE
LT GRN WIRE
MULTIFUNCTION SWITCH
NCA WIRE
ORG/ WIRE
PASSENGER AIR BAG MODULE
PASSENGER AIR BAG OFF IND
PASSENGER SIDE FRONT SEAT
PNK (OR WIRE
PNK WIRE
PPL SHIELD
RED WIRE
RIGHT FRONT DOOR SATELLITE SENSOR
RIGHT SEAT BELT PRE-TENSIONER
RIGHT SIDE AIR BAG MODULE
SEAT BELT BUCKLE SWITCH
SHIELD
SHIELD PPL
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> MULTIFUNCTION SWITCH
