Infiniti M56 IV (2010-2013) local comm 2 shield gnd sens power 1 shield Wiring diagram
This page shows the only wiring diagram for the component.local comm 2 shield gnd sens power 1 shield, which is found in the car Infiniti M56 IV (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram local comm 2 shield gnd sens power 1 shield (1 of 1)
BLK WIRE
BLU WIRE
BRAKE PEDAL STROKE SENSOR
BRN WIRE
BUCKLE SW LH NO
BUCKLE SW RH NO
CAN HI
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DRIVER SIDE FRONT SEAT
DRIVER'S SIDE PRE-CRASH SEAT BELT CONTROL UNIT (BASE OF LEFT "B" PILLAR)
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK J
FUSIBLE LINK K
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK (J/B) (BEHIND FUSE 6 LEFT END OF DASH)
ICC
LOCAL COMM 1
LOCAL COMM 1 SENS GND 1 SIG GND MOTOR BAT MOTOR GND
LOCAL COMM 2 SHIELD GND SENS POWER 1 SHIELD
LT GRN WIRE
ORG/ WIRE
OUT 1 -
OUT 2 +
PASSENGER SIDE FRONT SEAT
PASSENGER SIDE PRE-CRASH SEAT BELT CONTROL UNIT
PCB
PNK 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 SIG BAT WIRE
PNK CAN LO WIRE
PNK CAN-L WIRE
PPL
PPL 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 SIG BAT OUT 1
PPL LOCAL COMM 2
RED WIRE
SEAT BELT BUCKLE SWITCH
SHIELD
SIG GND MOTOR BAT MOTOR GND
VCC
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Passive restraints circuit -> LOCAL COMM 2 SHIELD GND SENS POWER 1 SHIELD
