Infiniti M56 IV (2010-2013) dim sig step lp cont can-h can-l Wiring diagram
This page shows the only wiring diagram for the component.dim sig step lp cont can-h can-l, which is found in the car Infiniti M56 IV (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dim sig step lp cont can-h can-l (1 of 1)
110 113 114 PPL PNK COMPUTER DATA LINES SYSTEM WIRE
ACTIVE NOISE CONTROL UNIT (REAR OF VEHICLE)
BCM (BODY CONTROL
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM PNK WIRE
DIM SIG STEP LP CONT CAN-H CAN-L
ECM (ENGINE CONTROL MODULE)
FRONT MICROPHONE
FRONT MICROPHONE (ACTIVE NOISE CONTROL)
GRN WIRE
GRY WIRE
LEFT FRONT DOOR SPEAKER
LEFT FRONT DOOR SQUAWKER
LEFT REAR DOOR SPEAKER
LT BLU WIRE
LT GRN WIRE
MODULE (BEHIND LEFT SIDE OF DASH)
ORG/ WIRE
PCB HARNESS
PNK WIRE
PPL
PPL PPL PNK WIRE
REAR MICROPHONE
REAR MICROPHONE (ACTIVE NOISE CONTROL)
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT DOOR SQUAWKER
RIGHT REAR DOOR SPEAKER
SHIELD
SOUND SIG FR DR SPKR&SQU LH-
SOUND SIG FR DR SPKR&SQU RH-
SOUND SIG FR LH-
SOUND SIG FR RH-
SOUND SIG FRONT LH (-)
SOUND SIG FRONT RH (-)
SOUND SIG REAR LH (-)
SOUND SIG REAR RH (-)
SOUND SIG RR DR SPKR LH+
SOUND SIG RR DR SPKR RH+
SOUND SIG RR LH (+)
SOUND SIG RR RH (+)
STEP LAMP CONT
TACHO
WHT WIRE
YEL WIRE
