Infiniti M56 IV (2010-2013) a/t shift selector shift lock unit Wiring diagram
This page shows the only wiring diagram for the component.a/t shift selector shift lock unit, which is found in the car Infiniti M56 IV (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/t shift selector shift lock unit (1 of 1)
4 3 6 1 GND COMM-H COMM-L IGN
A/T SHIFT SELECTOR SHIFT LOCK UNIT
BLK WIRE
BLK/YEL WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
FUSE 3 (BEHIND LEFT END OF DASH)
FUSE 7
FUSE BLOCK (J/B)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ICC BRAKE HOLD RELAY (W/ ICC) (IN FUSE, FUSIBLE LINK, RELAY BOX)
ICC SENSOR (LEFT SIDE OF FRONT BUMPER)
LT BLU WIRE
LT GRN WIRE
PCB HARNESS
PPL
PPL 1 2
SHIFT LOCK RELAY (W/ ICC) (IN FUSE, FUSIBLE LINK, RELAY BOX)
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
W/ ICC W/O ICC
W/O ICC W/ ICC
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> A/T SHIFT SELECTOR SHIFT LOCK UNIT
