Infiniti M45 III facelift (2008-2010) Ground distribution circuit

Ground distribution circuit (1 of 3)

Car Wiring Diagrams for M45 Infiniti III facelift (2008-2010): Ground distribution circuit (1 of 3)

BLK WIRE BLK/YEL WIRE RIGHT END OF DASH)

Ground distribution circuit (2 of 3)

Car Wiring Diagrams for M45 Infiniti III facelift (2008-2010): Ground distribution circuit (2 of 3)

BLK WIRE CONDENSER CONDENSER, A/T ASSEMBLY (TERMINAL 5, 10), TCM (TRANSMISSION CONTROL MODULE) IGNITION COIL 7 (W/ POWER TRANSISTOR), IGNITION COIL 8 (W/ POWER TRANSISTOR)

Ground distribution circuit (3 of 3)

Car Wiring Diagrams for M45 Infiniti III facelift (2008-2010): Ground distribution circuit (3 of 3)

ALTERNATOR BLK WIRE DVD PLAYER (TERMINAL 49) RAS MOTOR REAR WINDOW DEFOGGER SHIELD WIRE (CRASH ZONE SENSOR) SHIELD WIRE (AIR BAG DIAGNOSIS SENSOR UNIT)
