Infiniti M45 III facelift (2008-2010) shield strg sw a strg sw b Wiring diagrams

AV COMM (H) AV COMM (L) AV COMM (H) AV COMM (L) CAN H CAN L AV CONTROL UNIT BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM CONN RECOG DOWN ENTER SWITCH FUSE 37 FUSE 6 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK, RELAY BOX (RIGHT REAR OF ENGINE COMPT) GRN WIRE HOT AT ALL TIMES HOT IN ACC OR ON IGN PKB RV SPEED PNK WIRE ILL CONT (ILL+) ILLUM INSTRUMENT CLUSTER SYSTEM LT GRN WIRE MENU SWITCH MIC SIG MIC VCC MIC VCC SHIELD MIC SIG MICROPHONE NCA WIRE OFF ORG/ WIRE ORG/BLU WIRE PNK PNK WIRE PNK WIRE PPL RED WIRE RED/YEL WIRE RIGHT END OF DASH) SHIELD SHIELD STRG SW A STRG SW B SOUND RH SOURCE SWITCH STEERING SWITCH UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER CONSOLE) VOLUME VOLUME PUSH TO BACK SWITCH SWITCH TALK SWITCH (-) SWITCH (+) WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE

AV COMM (H) AV COMM (L) AV COMM (H) AV COMM (L) CAN H CAN L AV CONTROL UNIT BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM CONN RECOG DOWN ENTER SWITCH FUSE 37 FUSE 6 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK, RELAY BOX (RIGHT REAR OF ENGINE COMPT) GRN WIRE HOT AT ALL TIMES HOT IN ACC OR ON IGN PKB RV SPEED PNK WIRE ILL CONT (ILL+) ILLUM INSTRUMENT CLUSTER SYSTEM LT GRN WIRE MENU SWITCH MIC SIG MIC VCC MIC VCC SHIELD MIC SIG MICROPHONE NCA WIRE OFF ORG/ WIRE ORG/BLU WIRE PNK PNK WIRE PNK WIRE PPL RED WIRE RED/YEL WIRE RIGHT END OF DASH) SHIELD SHIELD STRG SW A STRG SW B SOUND RH SOURCE SWITCH STEERING SWITCH UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER CONSOLE) VOLUME VOLUME PUSH TO BACK SWITCH SWITCH TALK SWITCH (-) SWITCH (+) WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE
