Infiniti M45 III facelift (2008-2010) left side turn signal lamp Wiring diagram
This page shows the only wiring diagram for the component.left side turn signal lamp, which is found in the car Infiniti M45 III facelift (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side turn signal lamp (1 of 1)
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BRACKET)
BRK RLY
FUSE 20
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
GRN/WHT WIRE
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
ICC SENSOR INTEGRATED UNIT (LOWER FRONT OF ENGINE COMPT)
LEFT LICENSE PLATE LAMP
LEFT REAR COMBINATION LAMP
LEFT SIDE TURN SIGNAL LAMP
NCA WIRE
PNK WIRE
PNK/BLU WIRE
PPL
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP
SIDE MARKER
STOP
STOP LAMP SWITCH (ON BRAKE PEDAL
TAIL
TURN
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 3) -> LEFT SIDE TURN SIGNAL LAMP
