Infiniti M45 III facelift (2008-2010) dn up dn up up dn front rear lifting lifting switch switch Wiring diagram
This page shows the only wiring diagram for the component.dn up dn up up dn front rear lifting lifting switch switch, which is found in the car Infiniti M45 III facelift (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dn up dn up up dn front rear lifting lifting switch switch (1 of 1)
BAT (F/L)
BCM BAT (BODY (FUSE) CONTROL MODULE) (BEHIND RIGHT SIDE OF DASH) GND
BK FD FD BK LUMBAR SUPPORT SWITCH
BK FD FD BK SLIDING RECLINING SWITCH SWITCH
BLK WIRE
DN UP
DN UP DN UP UP DN FRONT REAR LIFTING LIFTING SWITCH SWITCH
FD BK
FRONT REAR LIFTING LIFTING MOTOR MOTOR
FUSE 21
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK, RELAY BOX (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK F
HOT AT ALL TIMES
LUMBAR SUPPORT MOTOR
NCA WIRE
ORG/ WIRE
PASSENGER SIDE FRONT SEAT
PASSENGER SIDE POWER SEAT SWITCH
PNK WIRE
POWER WINDOW POWER SUPPLY (BAT)
RED WIRE
RIGHT END OF DASH)
SLIDING RECLINING MOTOR MOTOR
WHT WIRE
Go to component -> Passenger power seat circuit -> DN UP DN UP UP DN FRONT REAR LIFTING LIFTING SWITCH SWITCH
