Infiniti M45 III (2005-2008) up dn front lifting motor Wiring diagram

33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 BAT (PTC) 39 40 37 COMPUTER DATA LINES SYSTEM CAN-H CAN-L KEY SW SIG PNK WIRE BACKWARD RECLINING SWITCH BACKWARD SLIDING SWITCH BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH) BRN/WHT WIRE BWD FWD CAN L CAN-H CANCEL SW CIRCUIT BREAKER (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DOOR SW (DR) DRIVER SEAT CONTROL UNIT (UNDER DRIVER SEAT) DRIVER SIDE FRONT POWER SEAT SWITCH FORWARD/ FUSE 1 FUSE 21 FUSE 6 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK, RELAY BOX (RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK F FWD BWD FWD BWD LUMBAR SUPPORT MOTOR FWD BWD RECLINING MOTOR GND (SENSOR GND) GND (SIGNAL) GND POWER GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START IGN LIFTING SWITCH (FRONT) DN LIFTING SWITCH (REAR) DN LT BLU WIRE LT GRN WIRE LUMBAR SUPPORT SWITCH ORG/ WIRE PNK BAT (FUSE) BAT (F/L) GND WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE RECLINING MTR (RR) FR LIFT MTR (UP) RECLINING SENSOR RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RIGHT END OF DASH) SLIDING MTR (BKWD) UP DN FRONT LIFTING MOTOR VIO WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/WHT WIRE
