Infiniti M45 III (2005-2008) pnk pdu awake up wiring diagram
This page shows the only wiring diagram for the component.pnk pdu awake up, which is found in the car Infiniti M45 III (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
pnk pdu awake up wiring diagram (1 of 1)
4.5L 3.5L
B+ STARTER
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BRN/WHT WIRE
CPU B+
ENG SW
FUSE 71
FUSE 78
GND (SIGNAL)
GND POWER
GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INTELLIGENT KEY UNIT (LEFT KICK PANEL)
NCA WIRE
PNK PDU AWAKE UP WIRE
PUSH BUTTON IGNITION SWITCH
ST CONT
ST CONT LOW
START OUT
START RLY
STARTER MOTOR
STARTER RELAY
TCM A/T ASSEMBLY (AT REAR OF ENGINE COMPARTMENT)
TRANSMISSIONS SYSTEM
WHT/RED WIRE
Go to component -> Starting circuit -> PNK PDU AWAKE UP WIRE
