Infiniti M45 III (2005-2008) jumping connector Wiring diagrams
This page contains all the electrical diagrams for the component. jumping connector, in which he is found in the car Infiniti M45 III (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram jumping connector (1 of 2)
41 42 43 44 45 46 47 48 49 50 51 52 SOUND LH (+) SOUND RH (+) TX (AUDIO-SAT)
53 54 55 AMP ON AM-FM MAIN FM SUB
AM-FM MAIN
AMP ON
ANTENNA AMP
AUDIO UNIT (RIGHT END OF DASH)
BACK-UP
BAT (+) GND
BLK WIRE
BLK/PNK WIRE
BLK/RED (OR RED) WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
BUS H BUS L
COMBINATION SWITCH (SPIRAL CABLE)
DOWN
ENTER SWITCH
GRN WIRE
ILL
ILL CONT (ILL+)
JUMPING CONNECTOR
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LEFT TWEETER
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OFF
ORG/ WIRE
PNK 9 10 11 12 WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER
RX (SAT-AUDIO)
SAT ANT
SATELLITE RADIO ANTENNA
SHIELD SHIELD
SOUND FR (+) SOUND FR (-) SOUND RR (+) SOUND RR (-) STRG SW GND STRG SW B
SOUND LH (-)
SOUND LH (-) SOUND RH (-) SHIELD SHIELD
SPLITTER
STEERING SWITCH
SWITCH BACK
SWITCH MENU
SWITCH SOURCE
SWITCH TO TALK PUSH
SWITCH VOLUME
TEL VOICE (+) TEL VOICE (-) VOI GUI (+) VOI GUI (-)
TER ANT
TXD (SAT-AUDIO) RXD (AUDIO-SAT)
VIO WIRE
W/ AWD MODELS
W/ NAVIGATION SYSTEM, RAS
W/O NAVIGATION SYSTEM, RAS
WHT WIRE
WINDOW ANTENNA (MAIN)
WINDOW ANTENNA (SUB)
YEL WIRE
Go to component -> Base radio circuit, without mobile entertainment system (1 of 2) -> JUMPING CONNECTOR
